Dimensions

183.5 mm x 112 mm x 75 mm

Interface

3 x GE WAN / LAN ports

Button

H button for one-key pairing and WPS compatible;
Independent Reset

Light

1 state indicator light

Power

AC 100 – 240 V, consumption < 24 W

WLAN

802.11ac 2 x 2 & 802.11n 2 x 2 MU-MIMO, 1167 Mbps

Backhaul

5 GHz mesh Wi-Fi (867 Mbps)

App

HUAWEI smarthome App

Function

802.11v & 802.11s protocol, PPPoE / DHCP / static IP address WAN connection methods, Wi-Fi timer, guest Wi-Fi, device speed limiting, MAC address filter, parental control, VPN pass through, virtual server

Security

Anti-brute force algorithms, WPA-PSK / WPA2-PSK Wi-Fi encryption, firewall, DMZ, PAP / CHAP, DoS attack protection
